Shanghai TB Series middle-size farming wheel tractor, horsepower range from 50hp to 100hp, 4x4WD, equipped with top famous brands Sida or Quanchai engine, reinforced sealed front axle with better muddy-proof quality, gearbox 12F+12R shuttle shift, 3 point hitch with empowered hydraulic asending and descending, double PTO speed 540rpm and 720rpm, adjustable wheelbase, canopy or cabin for option, dual-action clutch with high torque, fuel consumption economical, competent to work in big-scale farms, orchards and shortway transportation.

TB 504
- Product Details
- Technical Specifications
Main Parameters | |
Brand | Shanghai |
Model | SH504 |
Engine Model | Quanchai/Sida |
Power | 36.8 kW |
Drive type | 4x4 WD |
Gears | F12+R12 |
Hydraulic Output | 2 group value |
PTO | 540/720 rpm |
Dimension(L*W*H) | 4020mm*1830mm*2730mm |
Weight | 3030kg |
Tyre type | 9.5-24/14.9-30(11.2-24/16.9-30) |
